SERVER ACC PSU 860W REDUNDANT/PWS-860P-1R2 SUPERMICRO

Description: The Supermicro PWS-860P-1R2 is an 80 Plus Platinum level redundant power supply capable of continuously supplying 800W/860W output power at 94% efficiency. Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages. Features a card edge output to interface with a 2×25 card edge connector. This power supply is designed to not only provide you reliable power to your Supermicro server but also protects it from over voltage, over current and short circuiting via protective circuitry embedded into the unit. Rest easy knowing your hardware will be up and running with a mean-time between failure (MTBF) of greater than 250,000 hours and an LED indicator to keep you informed on normal/abnormal conditions for your PSU. This power supply is redundant to safe-guard your system from power failure and allows for hot-swap replacement to eliminate system downtime. All materials contained comply with RoHS requirements and is certified by Supermicro.
Vendor Homepage: https://store.supermicro.com/800w-1u-pws-860p-1r2.html
Model: PWS-860P-1R2
Model name: PWS-860P-1R2
Case Type: 1U rack
PSU: Redundant-Power-Capable
PSU Output Power: 860
Efficiency: 80 PLUS PLATINIUM
Dimensions: 54.5 x 322 x 40.25mm
Units per Shipping Box: 1
Shipping Box Depth: 40
Shipping Box Height: 12
Shipping Box Weight: 1.12
Shipping Box Width: 13
Unit Calculated Volume: 0.00624
Product Net Weight: 1.12
Unit Calculated Weight: 1.12
CnCode: 85044095
Unit Box Width: 0.13
Unit Box Length: 0.4
Unit Box Height: 0.12
Full Description Line: Model name PWS-860P-1R2|Case Type 1U rack|PSU Redundant-Power-Capable|PSU Output Power 860 Watts|Efficiency 80 PLUS PLATINIUM|Dimensions 54.5 x 322 x 40.25mm
Category Code: SPU
