Description: > Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
> Max. decoding capability: 32 × 1080p@30 fps
> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.
> Supports IP cameras with a resolution up to 32 MP.
> Supports AcuPick with up to 32 channels.
> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 24-channel perimeter protection; 32-channel SMD Plus.
> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
> Supports N+M cluster, ISCSI.
> Supports EPTZ, and one-click arming and disarming.
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Network-Recorders/WizMind-Series/NVR5-XI/4HDD/NVR5432-XI
Number of Channels: 32
Number of drives/bays: 4
Desktop/pedestal: Yes
Rack: Yes
CPU: Embedded Linux
Integrated LAN: Gigabit
15pin D-sub: 2
Alarm In: 16
Alarm Out: 6
Audio-In: 1
Audio-Out: 2
eSATA: 1
HDMI: 2
RJ45: 2
RS232: 1
RS-485: 1
USB 2.0: 1
USB 3.0: 2
Power supply requirements: 100–240 VAC, 50-60 Hz
Power consumption: 13
Dimensions: 440.0 × 412.7 x 76.0 mm
Operating temperature range: –10 °C to +55 °C
Units per Shipping Box: 1
Shipping Box Depth: 53
Shipping Box Height: 21
Shipping Box Weight: 6.5
Shipping Box Width: 50
Unit Calculated Volume: 0.05565
Product Net Weight: 4.52
Unit Calculated Weight: 6.5
CnCode: 85219000
Unit Box Width: 0.5
Unit Box Length: 0.53
Unit Box Height: 0.21
Full Description Line: Channels 32|Drives/bays 4|Desktop/pedestal|Rack|CPU Embedded Linux|Integrated LAN Gigabit|2x15pin D-sub|2xHDMI|1xAudio-In|2xAudio-Out|1xRS232|1xUSB 2.0|2xUSB 3.0|1xeSATA|2xRJ45|1xRS-485|16xAlarm In|6xAlarm Out|Power supply requirements 100–240 VAC, 50-60 Hz|Power consumption 13 Watts|Dim. 440.0 × 412.7 x 76.0 mm|Temp. range –10 °C to +55 °C
Category Code: NVR
