Description: Dell 5G – Qualcomm (DW5932e) WWAN Card
This product has been tested and validated on Dell systems. It is supported by Dell Technical Support when used with a Dell system.
Operating Frequency Bands:
NR (n1, n2, n3, n5, n7, n8, n12, n13, n14, 18, n20, n25, n26, n28, n30, n38, n40, n41, n48, n53, n66, n70, n71, n75, n76, n77, n78, n79)
LTE (B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71)
UMTS/HSPA+ (1, 2, 4, 5, 8)
Network standard:
NR FR1 (Sub6) FDD/TDD
LTE FDD/TDD
WCDMA/HSPA+
GPS/GLONASS/Beidou/Galileo
Vendor Homepage: www.dell.com/en-ie/shop/dell-5g-qualcomm-dw5932e-wwan-card/apd/555-blgm/wifi-and-networking
Model name: DW5932E
PCIe Gen3: Yes
Depth: 30
Height: 2.6
Width: 42
Units per Shipping Box: 1
Shipping Box Depth: 28.5
Shipping Box Height: 4
Shipping Box Weight: 0.091
Shipping Box Width: 12
Unit Calculated Volume: 0.001368
Product Net Weight: 0.008
Unit Calculated Weight: 0.091
CnCode: 85176200
Unit Box Width: 0.12
Unit Box Length: 0.285
Unit Box Height: 0.04
Full Description Line: DW5932E|PCIe Gen3
Category Code: NBA
