Description: Pentabrid capability: Each channel supports up to 8MP: HDCVI, AHD, TVI, CVBS and 8MP IP Video input, Auto-detect
4-channel BNC interface
HDCVI/AHD/HD-TVI recording: 4K; 6MP; 5MP; 4MP; 3MP; 4M-N; 1080P; 720P; 960H; D1; CIF
Record Rate: All channel 4K (1 fps–7 fps); 6MP (1 fps–10 fps); 5MP (1 fps–12 fps); 4MP/3MP (1 fps–15 fps); 4M-N/1080p/720p/960H/D1/CIF (1 fps–25/30 fps)
IP: 4+4 channels, each channel up to 8MP; Max 64Mbps Incoming Bandwidth
AI Coding/H.265+/H.265/H.264+/H.264 video compression
G.711A, G.711U, PCM audio compression
1x SATA interface up to 10 TB storage
VGA/HDMI up to 3840 × 2160 output
RJ-45, 2x USB ports, RS485
No front panel control, 1/1 Audio I/O, no Alarm I/O
Compact 1U case, mouse included
ONVIF 16.12, CGI Conformant, Smart Search, Smart fan, Coax audio support
Third-party IP camera support: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Up to 1 channel video stream ( analog channel ) Perimeter Protection
Up to 4 channels video stream ( analog channel ) SMD Plus
Up to 1 channel video stream (analog channel ) human face recognition
IoT & POS functionalities
Free IP monitoring software available
Vendor Homepage: www.dahuasecurity.com/products/All-Products/HDCVI-Recorders/WizSense-Series/I3-Series/5MP-Series/XVR5104HS-4KL-I3
DVR type: 4 Channel
SATA: Yes
Camera Compatibility: AHD 1080P/AHD 5MP/AHD 720P/Analog/HDCVI 1080P/HDCVI 4MP/HDCVI 6MP/HDCVI 720P/HD-TVI/TurboHD 1080P/HD-TVI/TurboHD 3MP/HD-TVI/TurboHD 5MP/HD-TVI/TurboHD 720P/IP
Number of channels: 4
15pin D-sub: 1
Audio-In: 1
Audio-Out: 1
HDMI: 1
RJ45: 1
RS-485: 1
USB 2.0: 2
Power supply requirements: DC 12V/2A
Dimensions: 260.0 × 237.9 × 47.6mm
Units per Shipping Box: 1
Shipping Box Depth: 33.5
Shipping Box Height: 31.5
Shipping Box Weight: 1.42
Shipping Box Width: 9
Unit Calculated Volume: 0.009497
Product Net Weight: 0.53
Unit Calculated Weight: 1.42
CnCode: 85219000
Unit Box Width: 0.09
Unit Box Length: 0.335
Unit Box Height: 0.315
Full Description Line: 4 Channel|Camera Compatibility Analog/IP/AHD 720P/AHD 1080P/AHD 5MP/HDCVI 720P/HDCVI 1080P/HDCVI 4MP/HDCVI 6MP/HD-TVI/TurboHD 720P/HD-TVI/TurboHD 1080P/HD-TVI/TurboHD 3MP/HD-TVI/TurboHD 5MP|SATA|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|2xUSB 2.0|1xRJ45|1xRS-485|DC 12V/2A
Category Code: STD
