Description:
– Split-spectrum sensor technology
– Test and hush features in one single button
– Loud sound output over 85 dB(A) at 3 meters
– Low quiescent current consumption
– Surface-mount device (SMD) circuit board design
– Low battery warning signal
– Battery Life: 10 year, 3V CR123A lithium battery (replaceable)
– TÜV and CE listed, EN 14604:2005+AC:2008
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Fire-Alarm/Smoke-Alarms/HY-SA20A
Model: HY-SA20A
Detector Type: Fire
Operating temperature range: -10°C to +55°C
Power supply requirements: 3V CR123A lithium battery (replaceable)
Colour: White
Dimensions: φ98 mm × H43.1 mm
Units per Shipping Box: 1
Shipping Box Depth: 13.5
Shipping Box Height: 5.5
Shipping Box Weight: 0.18
Shipping Box Width: 10.5
Unit Calculated Volume: 0.0007796
Product Net Weight: 0.136
Unit Calculated Weight: 0.18
CnCode: 85311030
Unit Box Width: 0.105
Unit Box Length: 0.135
Unit Box Height: 0.055
Full Description Line: Detector Type Fire|Operating temperature range -10°C to +55°C|Power supply requirements 3V CR123A lithium battery (replaceable)|Colour White|Dimensions φ98 mm × H43.1 mm
Category Code: MDE
