Description: > Max. 30 fps@1080p.
> Smart IR Illumination.
> 30 m illumination distance.
> Super Adapt.
> Built-in Mic.
> Quick-to-install eyeball saves installation time.
> 3.6 mm fixed lens (2.8 mm optional).
> CVI/CVBS/AHD/TVI switchable.
> IP67, 12 VDC.
Vendor Homepage: www.dahuasecurity.com/ceen/products/All-Products/HDCVI-Cameras/Lite-Series/1080P/1080-P/HAC-HDW1200TLMQ(-A)=S6
Camera design: Eyeball
Network Camera Type: HDTV/Megapixel/Outdoor
Video interface: HDCVI
Pixel Resolution: 2
Net camera resolution: 2 – 4MP
Focal Length: 3.6mm
Focal length: 3.6 – 4mm
Lens Mount: M12
Min. Illumination: 0.001
IR Illumination: Yes
Effective pixels: 1920 (H) × 1080 (V)
Electronic Shutter Speed: PAL: 1/25 s–1/100000 s, NTSC: 1/30 s–1/100000 s
Microphone: Built-in
Power options: 12V
Power supply requirements: 12 VDC ± 30%
Power consumption: 3.2
Environment: Outdoor
Colour: White
Dimensions: Φ109.9 mm × 88.1 mm
Units per Shipping Box: 1
Shipping Box Depth: 13
Shipping Box Height: 12
Shipping Box Weight: 0.426
Shipping Box Width: 10.5
Unit Calculated Volume: 0.001638
Product Net Weight: 0.33
Unit Calculated Weight: 0.426
CnCode: 85258900
Unit Box Width: 0.105
Unit Box Length: 0.13
Unit Box Height: 0.12
Full Description Line: Type HDTV/Megapixel/Outdoor|Video interface HDCVI|Focal Length 3.6mm|Lens Mount M12|Min. Illumination 0.001 Lux|Effective pixels 1920 (H) × 1080 (V)|Electronic Shutter Speed PAL: 1/25 s–1/100000 s, NTSC: 1/30 s–1/100000 s|Microphone Built-in|Power supply requirements 12 VDC ± 30%|Colour White|Dimensions Φ109.9 mm × 88.1 mm
Category Code: HSC
